MODEL #WAL - R4
Model #WAL-R4 features an insulated thermal board and hardware layout custom manufactured as per your design. It is designed for smaller installations and is explosion proof.
High impact cast aluminum
High impact strength
Rust-proof
Fully Customizable
Withstand weather, ultraviolet light and time
Test lead wires installed as an extra
Dimensions of Terminal Board: W 10cm. x H 6.5cm. (approx.)
Outside Dimensions: W 11.5cm. x D 7.5cm. (approx.) (W 4 5/8" x D 3") (approx.)
1.9cm. (3/4") or 3.2cm. (1 1/4") aluminum conduit bushed into the box
Approx. weight 800 gr. (1 lb. 10 oz.)
A screw on vertical face cap is threaded and comes with an O ring seal
Available in models to fit 1.9cm. (3/4") and 3.2cm. (1 1/4") aluminum conduit
